Quincy Oil-less Two Stage Piston Compressors

Quincy two stage oil-less compressors provide clean air at pressures up to 150 psig. They are popular choices for laboratory applications. All models comply with EPA health standards, as they employ graphite gaskets and Teflon impregnated valve plates.

These air cooled models operate at slow speeds, minimizing heat, while extending service life. They feature cast iron crankcases, ductile iron crankshafts, totally sealed bearings, and deep cylinder fins for efficient cooling. High air temperature switches are included for protection of the compressor.

All models are offered as either a bare compressor, or a complete module, including inlet filter, motor, drive belt, belt guard, and aftercooler. All two stage modules are also equipped with solenoid valve unloading.

Quincy Oil-less Two Stage Piston Compressors
Module Model QRDT5B QRDT7.5B QRDT10B QRDT15B QRDT20B QRDT25B QRDT30B
Part # 230060 230062 230056 230057 230041 230042 230043
Motor HP 5 7.5 10 15 20 25 30
No. of Cylinders 2 2 3 3 4 4 4
Capacity @ 100 PSI (CFM) 19 25 38 50 81.5 100.0 115.0
Capacity @ 150 PSI (CFM) 16 22 37 50 72 87.0 100
Maximum Pressure (PSI) 150 150 150 150 150 150 150
Operating Speed @ 100 PSI (RPM) 731 1005 780 1020 705 870 1020
Weight (lb.) 680 690 840 1090 1400 1440 1445
Bare Compressor ONLY QRDT-7.5 QRDT-7.5 QRDT-15 QRDT-15 QRDT-30 QRDT-30 QRDT-30
Part # 230004 230004 230006 230006 230009 230009 230009
Weight (lb.) 295 295 400 400 735 735 735
